XIM505
• 12 Volt, A-Circuit, (N/C)-D-P Terminals, 14.4 Vset
• Mitsubishi ED/IF Alternators
• With capacitor plate
• Notes - 3-pin connector but only D-P are used: (N/C) = No connection. D = Drive. P = Phase,IM505 is NOT a traditional regulator, but a field control unit that works with the vehicles computer (PCM) to control the voltage and output. Traditional test methods will immediately damage D-P Type regulators. See VRC101-26 regulator test adapter.
• Replaces - MITSUBISHI A866X50572
-
XIM481
- C-S-L Terminals
- Voltage set point 14.5v
- Soft start
- 5 sec. LRC
- Short circuit protection
- Regulated voltage control (RVC)
- Replace: Mitsubishi: A866x54472,547,544
- Unit No: Mitsubishi: A3TG2681ZE, A3TG5381RL,
A003TG5381RL.
Nissan:23100-EB310
-
XIM529
• 12 Volt, A-Circuit, LI-RC-AS Terminals, 14.0 Vset
• Mitsubishi 150-200A IR/IF Alternators
• Notes - PCM controlled regulation voltage
• Replaces - MITSUBISHI 529, A866T52970
-
XIM541
• 24 Volt, A-Circuit, S(R)-L Terminals, 28.35 Vset
• Mitsubishi IR/IF Alternators
• Used on Mitsubishi 541 8823S,NF864420
• Dimensions:28mm ID Slip Ring Cover
• Also consider XIMT10090
-
XIM545
• 12 Volt, A-Circuit, FR-L Terminals, 14.4 Vset
• Mitsubishi IR/IF Alternators
• Stator activated
• Replaces - MITSUBISHI 866X54572
